A181 Datasheet - Tyco Electronics

A181 10 TO 1000 MHz CASCADABLE AMPLIFIER

A181/SMA181 10 TO 1000 MHz CASCADABLE AMPLIFIER HIGH REVERSE ISOLATION: 22 dB (TYP.) HIGH OUTPUT POWER: +22 dBm (TYP.) HIGH THIRD ORDER I.P.: +35 dBm (TYP.) Typical Performance @ 25°C Specifications (Rev. Date: 11/00) Characteristics Frequency Small Signal Gain (min.) Gain Flatness (max.) Reverse Isolation Noise Figure (max.) Power Output @ 1 dB comp. (min.) IP3 IP2 Second Order Harmonic IP VSWR Input / Output (max.) DC Current @ 15 Volts (max.) Typical 0° to 50°C Guaran.

A181 Datasheet (85.35 KB)

Preview of A181 PDF

Datasheet Details

Part number:

A181

Manufacturer:

Tyco Electronics

File Size:

85.35 KB

Description:

10 to 1000 mhz cascadable amplifier.
