CHR3764-QEG Integrated Down Converter

The CHR3764-QEG is a multifunction monolithic circuit, which integrates a balanced cold FET mixer, a multiplier by two, and a RF LNA including gain control. It is designed for a wide range of applications, typically ISM and commercial communication systems. The circuit is manufactured with a pHEMT p.

CHR3764-QEG Features

* Broadband RF performance 21-26.5GHz

* 13dB conversion gain

* 3.1dB Noise Figure, for IF>0.1GHz

* 1dBm Input IP3

* 14dB Gain Control

* 15dBc Image Rejection

* DC bias: Vd=4Volt @ Id=320mA

* 24L-QFN4x5

* MSL1 Conversion gain (dB) 18 16 14 12 10 8 6 4 2

CHR3764-QEG_UnitedMonolithicSemiconductors.pdf

CHR3764-QEG Datasheet Preview — Preview of CHR3764-QEG PDF

Datasheet Details

Part number:

CHR3764-QEG

Manufacturer:

United Monolithic Semiconductors

File Size:

683.13 KB

Description:

Integrated down converter.
