VBM1805 N-Channel MOSFET

VBM1805 www.VBsemi.com N-Channel 80 V (D-S) MOSFET PRODUCT SUMMARY VDS (V) RDS(on) (Ω) MAX.80 0.0048 at VGS = 10 V 0.0055 at VGS = 7.5 V ID .

VBM1805-VBsemi.pdf

VBM1805 Datasheet Preview — Preview of VBM1805 PDF

Datasheet Details

Part number:

VBM1805

Manufacturer:

VBsemi

File Size:

697.37 KB

Description:

N-Channel MOSFET

Features

* TrenchFET® power MOSFET
* Maximum 175 °C junction temperature
* Very low Qgd reduces power loss from passing through Vplateau

Applications

* D
* Power supply - Secondary synchronous rectification
* DC/DC converter
* Power tools G
* Motor drive switch
* DC/AC inverter
* Battery management S N-Channel MOSFET ABSOLUTE MAXIMUM RATINGS (TC = 25 °C, unless otherwise noted) PARAMETER
