MSM-0315, MSM-0305 Datasheet - VOLGEN

MSM-0315 1 WATT DC/DC CONVERTER

MSM-0315 Features

* ECONOMY LINE 7 PIN PACKAGE 1000 VDC ISOLATION UNREGULATED OUTPUT UL 94V-0 PACKAGE MATERIAL 3.3V ~ 24V INPUT MODELS ONE YEAR WARRANTY OUTPUT SPECIFICATIONS Output Voltage Accuracy ±5% Efficiency 75% typ. Ripple 100 mVp-p LineRegulation 1.2%/1% of V in Line Filter Built-in Load Regulation5V=15% max.

MSM-0305-VOLGEN.pdf

This datasheet PDF includes multiple part numbers: MSM-0315, MSM-0305. Please refer to the document for exact specifications by model.
MSM-0315 Datasheet Preview Page 2 MSM-0315 Datasheet Preview Page 3

Datasheet Details

Part number:

MSM-0315, MSM-0305

Manufacturer:

VOLGEN

File Size:

234.72 KB

Description:

1 watt dc/dc converter.

Note:

This datasheet PDF includes multiple part numbers: MSM-0315, MSM-0305.
Please refer to the document for exact specifications by model.
