VSO030C04MC
Features
- N+P Channel
- Enhancement mode
- Very low on-resistance
- Fast Switching
- Pb-free lead plating; Ro HS pliant
40V N+P Channel Advanced Power MOSFET
V DS R @DS(on),TYP VGS=±10 V R @DS(on),TYP VGS=±4.5V ID
40 -40 V 18 32 mΩ 24 38 mΩ 8 -6 A
SOP8
Part ID VSO030C04MC
Package Type SOP8
Absolute Maximum Ratings
Marking 030C04MC
Symbol
Parameter
Tape and reel information
3000pcs/Reel mon Ratings (TC=25°C Unless Otherwise Noted)
VGS Gate-Source Voltage
V(BR)DSS
TJ TSTG IS
Drain-Source Breakdown Voltage
Maximum Junction Temperature① Storage Temperature Range Diode Continuous Forward Current
Mounted on Large Heat Sink
IDM Pulse Drain Current Tested②
ID Continuous Drain Current
PD Power dissipation for Dual Operation RθJL Thermal Resistance-Junction to Lead RθJA Thermal Resistance Junction-Ambient
TA =25°C
TA =25°C TA =25°C TA =100°C TA =25°C
Rating NMOS PMOS
Unit
±20 ±20 40 -40
150 -50 to 150 2.4 -2.4
V V °C °C...
