B048F120T30 Datasheet - Vicor

B048F120T30 - Bus Converter

The V *I Chip Bus Converter Module is a high efficiency (>95%), narrow input range Sine Amplitude Converter (SAC) operating from a 38 to 55 Vdc primary bus to deliver an isolated 9.50 V to 13.8 V secondary.

The BCM may be used to power non-isolated POL converters or as an independent 9.50

B048F120T30 V I BCMTM Bus Converter 48 V to 12 V V I ChipTM Converter 300 Watt (450 Watt for 1 ms) High density 1036 W/in3 Small footprint 260 W/in2 Low weight 0.5 oz (15 g) ZVS / ZCS isolated Sine Amplitude Converter Typical efficiency 95% 125°C operation (TJ) <1 µs transient response 3.5 million hours MTBF No output filtering required ©

B048F120T30-Vicor.pdf

B048F120T30 Datasheet Preview — Preview of B048F120T30 PDF

Datasheet Details

Part number:

B048F120T30

Manufacturer:

Vicor

File Size:

537.58 KB

Description:

Bus converter.
