BCM380P475M1K2A3R Datasheet - Vicor

Fixed Ratio DC-DC Converter

BCM380P475M1K2A3R Features

* Up to 1200 W continuous output power

* 1876 W/in3 power density

* 97.9% peak efficiency

* 4,242 Vdc isolation

* Parallel operation for multi-kW arrays

* OV, OC, UV, short circuit and thermal protection

* 6123 through-hole ChiP package n 2.494

BCM380P475M1K2A3R General Description

The VI Chip® Bus Converter (BCM®) is a high efficiency Sine Amplitude Converter™ (SAC™), operating from a 260 to 410 VDC primary bus to deliver an isolated, ratiometric output from 32.5 to 51.3 VDC. The BCM380x475y1K2A3z offers low noise, fast transient response, and industry leading efficiency and .

BCM380P475M1K2A3R Datasheet (1.24 MB)

Preview of BCM380P475M1K2A3R PDF

Datasheet Details

Part number:

BCM380P475M1K2A3R

Manufacturer:

Vicor

File Size:

1.24 MB

Description:

Fixed ratio dc-dc converter.
