SIS407DN, P-Channel 20V MOSFET

www.vishay.com SiS407DN Vishay Siliconix P-Channel 20 V (D-S) MOSFET PowerPAK® 1212-8 Single D D8 D7 D6 5 3.3 mm 1 Top View 3.3 mm PRODUCT SUMM.

Features

* TrenchFET® power MOSFET
* Low thermal resistance PowerPAK® package with small size and low 1.07 mm profile
* 100 % Rg and UIS tested

Applications

* Load switch
* Battery switch S G D P-Channel MOSFET ORDERING INFORMATION Package Lead (Pb)-free and halogen-free PowerPAK 1212-8 SiS407DN-T1-GE3 ABSOLUTE MAXIMUM RATINGS (TA = 25 °C, unless otherwise noted) PARAMETER SYMBOL Drain-source voltage Gate-source voltage Continuou
