SM15T100A - Surface Mount Transient Voltage Suppressors
www.vishay.com SM15T Series Vishay General Semiconductor Surface Mount TRANSZORB® Transient Voltage Suppressors Cathode SMC (DO-214AB) Anode (unidirectional) (bidirectional) LINKS TO ADDITIONAL RESOURCES 3D 3D 3D Models PRIMARY CHARACTERISTICS VWM VBR unidirectional VBR bidirectional PPPM PD IFSM (uni-directional only) TJ max.
Polarity 5.8 V to 188 V 6.8 V to 220 V 6.8 V to 220 V 1500 W 6.5 W 200 A 150 °C Unidirectional, bidirectional Package SMC (DO-214AB) DEVICES FOR BIDIRECTION A
SM15T100A Features
* Low profile package Available
* Ideal for automated placement
* Glass passivated chip junction
* Available in unidirectional and bidirectional
* 1500 W peak pulse power capability with a 10/1000 μs waveform
* Excellent clamping capability Avai
