VS-8ETU04SHM3

Ultrafast Rectifier

VS-8ETU04SHM3 Features

* Ultrafast recovery time

* Low forward voltage drop

* Low leakage current

* 175 °C operating junction temperature

* Meets MSL level 1, per J-STD-020, LF maximum peak of 260 °C

* AEC-Q101 qualified, meets JESD 201, class 1 whisker test

* Materi

VS-8ETU04SHM3 General Description

/ APPLICATIONS Vishay Semiconductors FRED Pt® series are the state of the art ultrafast recovery rectifiers specifically designed with optimized performance of forward voltage drop and ultrafast recovery time. The planar structure and the platinum doped life time c.

VS-8ETU04SHM3 Datasheet (190.28 KB)

Preview of VS-8ETU04SHM3 PDF

Datasheet Details

Part number:

VS-8ETU04SHM3

Manufacturer:

Vishay ↗

File Size:

190.28 KB

Description:

Ultrafast rectifier.
www.vishay.com VS-8ETU04SHM3, VS-8ETU04-1HM3 Vishay Semiconductors Ultrafast Rectifier, 8 A FRED Pt® TO-263AB (D2PAK) TO-262AA Base cathode 2 2 .
