VS-GT100TP120N Datasheet, Igbt, Vishay

VS-GT100TP120N Features

• Igbt
• Low VCE(sat) trench IGBT technology
• 10 μs short circuit capability
• VCE(sat) with positive temperature coefficient
• Maximum junction temperature 17

PDF File Details

Part number:

VS-GT100TP120N

Manufacturer:

Vishay ↗

File Size:

183.81kb

Download:

📄 Datasheet

Description:

Half bridge igbt. Vishay’s IGBT power module provides ultra low conduction loss as well as short circuit ruggedness. It is designed for applications su

VS-GT100TP120N Application

• Applications
• UPS (Uninterruptable Power Supply)
• Inverter for motor drive
• AC and DC servo drive amplifier DESCRIPTION V
