ESD5Z12 Transient Voltage Suppressors

* The ESD5Z Series is designed to protect voltage sensitive components from ESD and transient voltage events. Excellent clamping capability, low leakage, and fast response time, make these parts ideal for ESD protection on designs where board space is at a premium. Because of its small size, it.

ESD5Z12 Features

* Stand

* o Voltage: 2.5 V

* 12 V

* Peak Power up to 200 Watts @ 8 x 20 µs Pulse

* Low Leakage

* Response Time is Typically < 1 ns

* ESD Rating of Class 3 (> 16 kV) per Human Body Model

* IEC61000

* 4

* 2 Level 4 ESD Protection

* IEC61000

ESD5Z2.5-WEITRON.pdf

ESD5Z12 Datasheet Preview — This datasheet PDF includes multiple part numbers: ESD5Z12, ESD5Z2.5. Please refer to the document for exact specifications by model.

Datasheet Details

Part number:

ESD5Z12, ESD5Z2.5

Manufacturer:

WEITRON

File Size:

368.49 KB

Description:

Transient voltage suppressors.

Note:

This datasheet PDF includes multiple part numbers: ESD5Z12, ESD5Z2.5.
Please refer to the document for exact specifications by model.
