1N5225B - 500mW ZENER DIODE

Product Overview

WON-TOP

📥 Download Datasheet

1N5225B 500mW ZENER DIODE by WON-TOP - Datasheet Preview — Datasheet preview – 1N5225B

Datasheet Details

Part number	1N5225B
Manufacturer	WON-TOP
File Size	85.45 KB
Description	500mW ZENER DIODE
Datasheet	1N5225B Datasheet
Note	This datasheet PDF includes multiple part numbers: 1N5225B, 1N5221B-WON. Please refer to the document for exact specifications by model.
Additional preview pages of the 1N5225B datasheet.

Product details

Features

Planar Die Construction.
500mW Power Dissipation.
2.4V.
47V Nominal Zener Voltage.
5% Standard Vz Tolerance.
Low Inductance.
For Use in Voltage Regulator or Reference.
Plastic Case Material has UL Flammability Classification Rating 94V-0 Mechanical Data.
Case: DO-35, Molded Glass.
Terminals: Plated Leads Solderable per MIL-STD-202, Method 208.
Polarity: Cathode Band.
Weight: 0.13 grams (approx. ).
Mounting Position: Any.
M.
