W99132EX Datasheet, Controller, Winbond

W99132EX Features

• Controller
• 8-Bit CMOS microcontroller
• Up to 50 MHz operation
• Additional instructions of memory to memory move with two 16-bit Data Pointers
• 256-byte Scratch

PDF File Details

Part number:

W99132EX

Manufacturer:

Winbond

File Size:

48.28kb

Download:

📄 Datasheet

Description:

Vcd controller. The W99132 is a VCD microcontroller with standard 80C32 core. It contains embedded 12KB SRAM without external memory anymore. It prov

W99132EX Application

• Applications l l l VCD player DVD player Multimedia system The following figure shows a typical VCD player connection diagram of W99132 EEPROM W2
