SD1040 Features
* Schottky Barrier Chip
* Guard Ring for Transient and ESD Protection
* Surge Overload Rating to 180A Peak
* Low Power Loss, High Efficiency
* Ideally Suited for Use in High Frequency SMPS, Inverters and As Free Wheeling Diodes Mechanical Data
* Case: DO-201AD, Molded Plastic
Datasheet Details
SD1040, SD1030-Won
Won-Top Electronics
39.83 KB
10a schottky barrier diode.
This datasheet PDF includes multiple part numbers: SD1040, SD1030-Won.
Please refer to the document for exact specifications by model.
