WS2821 - Parallel-Single wire-Three channels 256 Gray level Constant current LED driver

Worldsemi

Datasheet Details

Part number	WS2821
Manufacturer	Worldsemi
File Size	604.92 KB
Description	Parallel-Single wire-Three channels 256 Gray level Constant current LED driver
Datasheet	WS2821-Worldsemi.pdf

Signal adopts the single line parallel connection type,any pixels’ failure won’t effect other pixel’s display effect.
Signal can compatible and expand the DMX512(1990) protocol signal.
Data transmission speed is 250Kbps~750Kbps.
The built-in voltage regulator chip, 5V above 24V power supply only series resistance to IC VDD feet, without additional voltage regulator tube.
WS2821 IC has VR-tube(voltage-regulator tube) built-in,for higher than 5V,lower than 24V’s power.
