* AEC-Q200 qualified
* Moisture sensitivity level: MSL 1
* AC series soldering is compliant with J-STD-020D
* Halogen free epoxy
* RoHS compliant - Products with lead-free terminations meet RoHS requirements - Pb-glass contained in electrodes, resistor element and glass are exemp
AC2010
YAGEO
739.83 KB
Thick film chip resistors.
DATA SHEET
THICK FILM CHIP RESISTORS
AUTOMOTIVE GRADE
AC series
±5%, ±1%, ±0.5%
Sizes 0201/0402/0603/0805/1206/ 1210/1218/2010/2512
RoHS compliant & H.
