MT3510A Datasheet, Rectifier, Yangzhou Yangjie

MT3510A Features

• Rectifier
• UL recognition, file #E230084
• Low thermal resistance
• Glass passivated chip junction
• High surge current capability
• Solder dip 275 °C max

PDF File Details

Part number:

MT3510A

Manufacturer:

Yangzhou Yangjie

File Size:

321.19kb

Download:

📄 Datasheet

Description:

Three phase bridge rectifier.

MT3510A Application

• Applications General purpose use in AC/DC bridge full wave rectification for Server、Frequency converter、Industrial power supply. Mechanical Data
