VP5511B

(VP5311B / VP5511B) NTSC/PAL Digital Video Encoder

VP5511B Features

* s Converts Y, Cr, Cb data to analog composite video and S-video s Supports CCIR recommendations 601 and 656 s All digital video encoding s Selectable master/slave mode for sync signals s Switchable chrominance bandwidth s Switchable pedestal with gain compensation s SMPTE 170M NTSC or CCIR 624 PAL c

VP5511B General Description

Pin Name PD0-7 D0-7 PXCK CLAMP Pin No. 39 - 46 3 - 10 15 17 Description 8 Bit Pixel Data inputs clocked by PXCK. PD0 is the least significant bit, corresponding to Pin 46. These pins are internally pulled low. 8 Bit General Purpose Port input/output. D0 is the least significant bit, corresponding t.

VP5511B Datasheet (315.21 KB)

Preview of VP5511B PDF

Datasheet Details

Part number:

VP5511B

Manufacturer:

Zarlink Semiconductor

File Size:

315.21 KB

Description:

(vp5311b / vp5511b) ntsc/pal digital video encoder.
