ZSR500N8

2.85 TO 12 VOLT FIXED POSITIVE LOCAL VOLTAGE REGULATOR

ZSR500N8 Features

* Small outline SO8 and SOT223 package

* TO92 package

* 2.85 to 12 Volt

* Output current up to 200mA

* Tight initial tolerance

* Low quiescent current

* -55 to 125°C temperature range

* No external components

* Internal thermal

ZSR500N8 Datasheet (421.15 KB)

Preview of ZSR500N8 PDF

Datasheet Details

Part number:

ZSR500N8

Manufacturer:

Zetex Semiconductors

File Size:

421.15 KB

Description:

2.85 to 12 volt fixed positive local voltage regulator.
