AS3608 - System PMU

Product Overview

austriamicrosystems

Part number	AS3608
Manufacturer	austriamicrosystems
File Size	1.88 MB
Description	System PMU
Datasheet	AS3608 Datasheet
Additional preview pages of the AS3608 datasheet.

The AS3608 is an ultra compact System PMU with integrated battery charger and HV back light driver.

3 DCDC converters as well as 5 low noise LDOs. The different regulated supply voltages are programmable via the serial control interface. The step-up converter for the backlight can operate up to 30V. Both constant voltage (OLED supply) as well as constant current (white LED backlight) operations with 2 current sinks are possible. An internal voltage protection is limiting the output voltage in the case of external component failures. AS3608 also contains a Li-Ion battery charger with constant c.
