54HC240 Datasheet, Drivers, Texas Instruments

54HC240 Features

• Drivers
• HC/HCT240 Inverting
• HC/HCT241 Non-inverting
• HC/HCT244 Non-inverting
• Typical propagation delay = 8ns at VCC = 5 V, CL = 15 pF, TA = 25℃ for HC240

PDF File Details

Part number:

54HC240

Manufacturer:

Texas Instruments ↗

File Size:

1.56MB

Download:

📄 Datasheet

Description:

High-speed cmos logic octal buffer/line drivers. The ’HC240 and ’HCT240 are inverting three-state buffers having two active-low output enables. The CD74HC241, ’HCT241, ’HC244 and ’H

54HC240 Application

• Applications intellectual property matters and other important disclaimers. PRODUCTION DATA. CD54HC240, CD74HC240, CD74HC241, CD54HC244 CD74HC244,

TAGS

54HC240

Texas Instruments
