CD74HC541E Datasheet, Drivers, Texas Instruments

CD74HC541E Features

• Drivers
• ’HC540, CD74HCT540: inverting
• ’HC541, ’HCT541: non-inverting
• Buffered inputs
• Three-state outputs
• Bus line driving capability

PDF File Details

Part number:

CD74HC541E

Manufacturer:

Texas Instruments ↗

File Size:

1.43MB

Download:

📄 Datasheet

Description:

Octal buffer and line drivers. The ’HC540 and CD74HCT540 are Inverting Octal Buffers and Line Drivers with Three-State Outputs and the capability to drive 15 LSTTL
