DRV8303 - Three-Phase Gate Driver

DRV8303 Description

Product Folder Sample & Buy Technical Documents Tools & Software Support & Community Reference Design DRV8303 SLOS846C * SEPTEMBER 2013 .
The DRV8303 is a gate driver IC for three-phase motor-drive applications.

DRV8303 Features

* 1 6-V to 60-V Operating Supply Voltage Range
* 1.7-A Source and 2.3-A Sink Gate Drive Current Capability
* Slew Rate Control for EMI Reduction
* Bootstrap Gate Driver With 100% Duty Cycle Support
* 6 or 3 PWM Input Modes
* Dual Integrated Current-Shun

DRV8303 Applications

* 3-Phase BLDC and PMSM Motors
* CPAP and Pump
* E-Bikes
* Power Tools
* Robotics and RC Toys
