LMH6702QML Datasheet, Amp, Texas Instruments

LMH6702QML Features

• Amp 1
• 2 VS = ±5V, TA = 25°C, AV = +2V/V, RL = 100Ω, VOUT = 2VPP, Typical Unless Noted:
• Available with Radiation Ensurance
    – High Dose Rate 300 krad(Si)

PDF File Details

Part number:

LMH6702QML

Manufacturer:

Texas Instruments ↗

File Size:

583.07kb

Download:

📄 Datasheet

Description:

1.7-ghz ultra-low distortion wideband op amp. The LMH6702 is a very wideband, DC coupled monolithic operational amplifier designed specifically for wide dynamic range systems requ

LMH6702QML Application

• Applications
• Flash A/D Driver
• D/A transimpedance Buffer
• Wide Dynamic Range IF Amp
• Radar/Communication Receiv
