SK18752

20W Audio Power Amplifier

SK18752 Features

* 1

* 2 Up to 30 Watts Output Power

* AVO Typically 90 dB

* Low Distortion: 0.015%, 1 kHz, 20 W

* Wide Power Bandwidth: 70 kHz

* Protection for AC and DC Short Circuits to Ground

* Thermal Protection with Parole Circuit

* High Current Capability:

SK18752 General Description

The LM1875 is a monolithic power amplifier offering very low distortion and high quality performance for consumer audio applications. The LM1875 delivers 20 watts into a 4Ω or 8Ω load on ±25V supplies. Using an 8Ω load and ±30V supplies, over 30 watts of power may be delivered. The amplifier is desi.

SK18752 Datasheet (3.25 MB)

Preview of SK18752 PDF

Datasheet Details

Part number:

SK18752

Manufacturer:

Texas Instruments ↗

File Size:

3.25 MB

Description:

20w audio power amplifier.
