SN74ABT827 - 10-Bit Buffer/Drivers
SN54ABT827 .
.
.
JT PACKAGE SN74ABT827 .
.
.
DB, DW, NT, OR PW PACKAGE (TOP VIEW) OE1 1 A1 2 A2 3 A3 4 A4 5 A5 6 A6 7 A7 8 A8 9 A9 10 A10 11 GND 12 24 VCC 23 Y1 22 Y2 21 Y3 20 Y4 19 Y5 18 Y6 17 Y7 16 Y8 15 Y9 14 Y10 13 OE2 SN54ABT827 .
.
.
FK PACKAGE (TOP VIEW) A2 A1 OE1 NC VCC Y1 Y2 These 10-
SN54ABT827, SN74ABT827 10ĆBIT BUFFERS/DRIVERS WITH 3ĆSTATE OUTPUTS SCBS159E JANUARY 1991 REVISED APRIL 2005 D State-of-the-Art EPIC-ΙΙB BiCMOS Design Significantly Reduces Power Dissipation D Flow-Through Architecture Optimizes PCB Layout D Latch-Up Performance Exceeds 500 mA Per JEDEC Standard JESD-17 D Typical VOLP (Output Ground Bounce) < 1 V at VCC = 5 V, TA = 25°C D High-Impedance State During Power Up and Power Down D High-Drive Outputs ( 32-mA IOH, 64-mA IOL)
