UCC1803 Datasheet, Controllers, Texas Instruments

UCC1803 Features

• Controllers
• 1 100-μA Typical Starting Supply Current
• 500-μA Typical Operating Supply Current
• Operation up to 1 MHz
• Internal Soft Start
• Internal Faul

PDF File Details

Part number:

UCC1803

Manufacturer:

Texas Instruments ↗

File Size:

3.02MB

Download:

📄 Datasheet

Description:

Low-power bicmos current-mode pwm controllers. The UCCx80x family of high-speed, low-power integrated circuits contain all of the control and drive components required for off-line

UCC1803 Application

• Applications
• Switch Mode Power Supplies (SMPS)
• DC-to-DC Converters
• Power Modules
• Industrial PSU
• Ba
