74HC00BQ Datasheet - nexperia

Quad 2-input NAND gate

* Wide supply voltage range from 2.0 V to 6.0 V

* CMOS low power dissipation

* High noise immunity

* Latch-up performance exceeds 100 mA per JESD 78 Class II Level B

* Input levels:

* For 74HC00: CMOS level

* For 74HCT00: TTL level

* Co

74HC00BQ

263.27 KB

Quad 2-input nand gate.
