NCA9547A-Q100 Description

NCA9547A-Q100 8-channel I²C-bus multiplexer with reset Rev.1 * 20 August 2025 Product data sheet 1.General .
The NCA9547-Q100 is an octal bidirectional translating multiplexer controlled by the I²C-bus.

NCA9547A-Q100 Features

* Automotive product qualification in accordance with AEC-Q100 (Grade 1)
* Specified from -40 °C to +85 °C and from -40 °C to +125 °C
* 1-of-8 bidirectional translating multiplexers
* I²C-bus interface logic; compatible with SMBus standards
* Active LOW reset

📥 Download Datasheet

NCA9547A-Q100 Datasheet Preview — Preview of NCA9547A-Q100 PDF

Datasheet Details

Part number: NCA9547A-Q100
Manufacturer: nexperia ↗
File Size: 689.85 KB
Datasheet: NCA9547A-Q100-nexperia.pdf
Description: 8-channel I2C-bus multiplexer
