TP2264-S Key Features
- Supply Voltage: 3 V to 36 V
- Low Supply Current: 1000 μA Maximum per Channel
- Differential Input Voltage Range to Supply Rail, can
- Input Rail to -VS, Rail-to-Rail Output
- Fast Response: 3.5-MHz Bandwidth, 15-V/μs Slew
- Low Offset Voltage
- ±2 mV Maximum at 25°C
- ±4 mV Maximum at -40°C to 125°C
- Excellent EMIRR: 60 dB at 900 MHz
- Operating Temperature Range: -40°C to 125°C
