ATmega328 Datasheet 8-bit Avr Microcontrollers

Manufacturer: Atmel (now Microchip Technology)

Overview: 8-bit AVR Microcontrollers ATmega328/P DATASHEET COMPLETE Introduction The Atmel® picoPower® ATmega328/P is a low-power CMOS 8-bit microcontroller based on the AVR® enhanced RISC architecture. By executing powerful instructions in a single clock cycle, the ATmega328/P achieves throughputs close to 1MIPS per MHz. This empowers system designer to optimize the device for power consumption versus processing speed.

Key Features

  • Two 8-bit Timer/Counters with Separate Prescaler and Compare Mode.
  • One 16-bit Timer/Counter with Separate Prescaler, Compare Mode, and Capture Mode.
  • Real Time Counter with Separate Oscillator.
  • Six PWM Channels.
  • 8-channel 10-bit ADC in TQFP and QFN/MLF package.
  • Temperature Measurement.
  • 6-channel 10-bit ADC in PDIP Package.
  • Temperature Measurement.
  • Two Master/Slave SPI Serial Interface.
  • One Programmable Seri.
