ATtiny45 - (Automotive) Atmel 8-bit AVR Microcontroller

This page provides the datasheet information for the ATtiny45, a member of the ATtiny25-1 (Automotive) Atmel 8-bit AVR Microcontroller family.

Product Overview

ATMEL

📥 Download Datasheet

ATtiny45 (Automotive) Atmel 8-bit AVR Microcontroller by ATMEL - Datasheet Preview — Datasheet preview – ATtiny45

Datasheet Details

Part number	ATtiny45
Manufacturer	ATMEL
File Size	2.59 MB
Description	(Automotive) Atmel 8-bit AVR Microcontroller
Datasheet	ATtiny45 Datasheet
Additional preview pages of the ATtiny45 datasheet.

ATtiny45 Product details

Features

High performance, low power AVR® 8-bit microcontroller.
Advanced RISC architecture.
120 powerful instructions.
most single clock cycle execution.
32 × 8 general purpose working registers.
Fully static operation.
Non-volatile program and data memories.
2/4/8Kbyte of in-system programmable program memory flash (ATtiny25/45/85).
Endurance: 10,000 write/erase cycles.
128/256/512 bytes in-system programmable EEPROM (Atmel® ATtiny25/45/85).
E.
