A085FW01-V4 Overview
Description
Ground for logic circuit 2 VCC I Supply voltage of logic control circuit for scan driver 3 VGL I Negative power for scan driver 4 VGH I Positive power for scan driver 5 STVD I/O Vertical start pulse 6 STVU I/O Vertical start pulse 7 CKV I Shift clock input for scan driver 8 U/D I UP/DOWN scan control input 9 OEV I Output enable input for scan driver 10 VCOM I Common electrode driving signal 11 VCOM I Common electrode driving signal 12 L/R I LEFT/RIGHT scan control input 13 MOD I Sequential sampling and simultaneous sampling setting 14 OEH I Output enable input for data driver 15 STHL.
