AG6201
Representative AG6201 image (package may vary by manufacturer)
Overview
ALGOLTEK AG6201 is a high-performance, cost effective single-chip solution to implement HDMI1.4 high resolution video to VGA converter. With embedded audio DAC, customers can save the BOM cost and reduce the PCB size.
- Video resolution support up to 1920x1200@60Hz
- Support Hot Plug Detection
- Embedded Crystal, Crystal-less in components
- Embedded 8-bit audio DAC
- Built-in 3.3V and 1.2V voltage regulators
- On-chip HDCP Engine which is compliant with HDCP 1.4 specification
- Integrated on-chip HDCP1.4 Keys
- 1.2V Core power and 3.3V I/O power
- 2KV ESD performance
- Operating temperature range: 0°C to +70°C 5 Public Release
