T113-S3
T113-S3 is Smart Control and Display SoC manufactured by Allwinner.
Smart Control and Display SoC for Automotive and Industrial Products
Features
- Dual-core ARM CortexTM-A7 CPU
- HiFi4 DSP
- Memories
- Embedded with 128 MB DDR3, clock frequency up to 800 MHz
- Three SD/MMC host controller (SMHC) interfaces: SD3.0/SDIO3.0/eMMC5.0
- Video Engine
- H.265/H.264/MPEG-1/MPEG-2/MPEG-4/JPEG/VC1/Xvid/Sorenson Spark decoding, up to 1080p@60fps
- JPEG/MJPEG encoding, up to 1080p@60fps
- Video and Graphics
- Allwinner SmartColor2.0 post processing for an excellent display experience
- Supports de-interlacer (DI) up to 1080p@60fps
- Supports Graphic 2D (G2D) hardware accelerator including rotate, mixer, LBC depression functions
- Video Output
- RGB...
