AZ1013-04C
Features
ESD Protect for Low-Voltage Differential Signaling (LVDS) channels Protects four I/O lines Provide ESD protection for each channel to IEC 61000-4-2 (ESD) ±30k V (air / contact) IEC 61000-4-4 (EFT) 80A (5/50ns) IEC 61000-4-5 (Lightning) 15A (8/20µs) For operating voltage of 3.3V and below Low capacitance : 1.8p F typical Fast turn-on and Low clamping voltage Array of surge rated diodes with internal equivalent TVS diode Solid-state silicon-avalanche and active circuit triggering technology Green Part
Applications
LVDS Interface USB2.0 Data Lines Protection Control Signal Lines Protection SIM Ports Monitors and Flat Panel Displays Notebook and PC puters Ethernet Port: 10/100/1000 Mb/s Consumer Electronics Set Top Box
Description
AZ1013-04C is a high performance design which includes surge rated diode arrays to protect high speed data interfaces. The AZ1013-04C has been specifically designed to protect sensitive ponents, which are connected to data and transmission lines, from...
