| Part number | AZ1015-02S |
|---|---|
| Datasheet | AZ1015-02S-AmazingMicroelectronic.pdf |
| File Size | 154.73 KB |
| Manufacturer | Amazing Microelectronic |
| Description | Low Capacitance ESD Protection Array For High Speed Data Interfaces |
|
|
immunity requirements of IEC 61000-4-2, Level 4 (± 15kV air, ±8kV contact discharge). Circuit Diagram 5 3 4 2 AZ1015-02S is a high performance design which includes surge rated diode arrays to protect high speed data interfaces. The AZ1015-02S has been specifically designed to protect sensitive ponents, which are connected to data and transmission lines, from over-voltage caused by Electrostatic Discharging (ESD),...
