AZ1743-04F
Features
Description
ESD Protect for Transition Minimized Differential Signaling (TMDS) channels Protects four I/O lines Provide ESD protection for each line to
IEC 61000-4-2 (ESD) ±15k V (air), ±11k V (contact) IEC 61000-4-5 (Lightning) 4A (8/20µs)
For operating voltage of 3.3V and below Ultra low capacitance : 0.4p F typical Fast turn-on and Low clamping voltage Array of ESD rated diodes with internal equivalent TVS (Transient Voltage Suppression) diode Solid-state silicon-avalanche and active circuit triggering technology Green part
Applications
High Definition Multi-Media Interface (HDMI) 1.3 & 1.4 and 2.0 version Display Port interface SATA and e SATA interface USB3.0 and USB3.1 V-By-One MIPI interface LVDS interface Desktop and Notebooks PCs Consumer Electronics Set Top Box
AZ1743-04F is a design which includes ESD rated diode arrays to protect high speed data interfaces. The AZ1743-04F has been specifically designed to protect sensitive ponents which are connected to data and...
