Ampleon BLF888AS
The excellent ruggedness of this device makes it ideal for digital and analog transmitter applications.| Part No. | BLF888AS |
|---|---|
| Datasheet | BLF888AS Download |
| Manufacturer |  Ampleon |
| Description | Power LDMOS transistor |
| Buy | Stock & Price |
BLF888A; BLF888AS UHF power LDMOS transistor Rev. 6 — 1 September 2015 Product data sheet 1. Product profile 1.1 General description A 600 W LDMOS RF power transistor for broadcast transmitter applications and industrial applications. Table 1. Application information RF performance at VDS = 50 V unless otherwise specified. Mode of operation f PL(AV) (MHz) (W) PL(M) (W) Gp (dB) D (%) RF performance in a common source narrowband test circuit CW 650 - 600 20 67 CW (42 V) 650 - 500 20 69 2-tone, class-AB pulsed, class-AB [1] f1 = 860; f2 = 860.1 860 250 - 21 46 - 600 20 58 DVB-T (8k OFDM) 858 110 - 21 31 858 125 - 21 32.5 RF performance in a common source 470 MHz to 860 MHz broadband test circuit DVB-T (8k OFDM) 858 110 - 20 30 858 120 - 20 31 IMD3 (dBc) 32 - - IMDshldr (dBc) 32 [2] 30 [2] 32 [2] 31 [2] PAR (dB) 8.2 [3] 8.0 [3]
