AD3531
AD3531 is 4-Channel 16-Bit Voltage Output DAC manufactured by Analog Devices.
Data Sheet AD3531/AD3531R
4-Channel, 16-Bit Voltage Output DAC, On-Chip Reference, SPI
Features
GENERAL DESCRIPTION
- 16-bit resolution, ±3 LSB16 INL, ±1 LSB16 DNL
- TUE: ±0.22% of FSR maximum
- Offset error: ±1.5mV maximum
- Gain error: ±0.26% of FSR maximum
- Guaranteed sourcing current of 100 mA
- Ultra-low headroom: 12mV at 20mA load
- 2.5V internal voltage reference, 5ppm/°C, typical
- 55nV/√Hz noise spectral density (external reference)
- 96nV/√Hz noise spectral density (internal reference)
- Output voltage, current, and die temperature monitors
- 50MHz SPI write and read
- 2.7V to 5.5V power supply range
- 1.2V or 1.8V patible digital interface
- Operating temperature range:
-...
