HCNW3120 - 2.5 Amp Output Current IGBT Gate Drive Optocoupler

General Description

The HCPL-3120 contains a GaAsP LED while the HCPL-J312 and the HCNW3120 contain an AlGaAs LED.

The LED is optically coupled to an integrated circuit with a power output stage.

These optocouplers are ideally suited for driving power IGBTs and MOSFETs used in motor control inverter applications.

📥 Download Datasheet

📁 Similar Datasheet

Part Number Description Manufacturer
HCNW3120 Agilent 2.5 Amp Output Current IGBT Gate Drive Optocoupler Agilent
HCNW135 High-Speed Optocouplers Broadcom
HCNW135 High Speed Optocouplers HP
HCNW136 High-Speed Optocouplers Broadcom
HCNW136 High Speed Optocouplers HP

Other Datasheets by Avago Technologies (now Broadcom)

Part Number Description
HCNW135 High Speed Optocouplers
HCNW136 High Speed Optocouplers
HCNW137 High Speed TTL Compatible Optocouplers
HCNW138 High Gain Optocouplers
HCNW139 High Gain Optocouplers

Full PDF Text Transcription (Reference)

The following content is an automatically extracted verbatim text from the original manufacturer datasheet and is provided for reference purposes only.

View original datasheet text
HCPL-3120/J312, HCNW3120 2.5 Amp Output Current IGBT Gate Drive Optocoupler Data Sheet Description The HCPL-3120 contains a GaAsP LED while the HCPL-J312 and the HCNW3120 contain an AlGaAs LED. The LED is optically coupled to an integrated circuit with a power output stage. These optocouplers are ideally suited for driving power IGBTs and MOSFETs used in motor control inverter applications. The high operating voltage range of the output stage provides the drive voltages required by gate controlled devices. The voltage and current supplied by these optocouplers make them ideally suited for directly driving IGBTs with ratings up to 1200 V/100 A. For IGBTs with higher ratings, the HCPL-3120 series can be used to drive a discrete power stage which drives the IGBT gate.
