PRODUCT SPECIFICATION Doc. Number: Tentative Specification Preliminary Specification Approval Specification MODEL NO.: N140BGE SUFFIX: L22 Customer: CMI Standard Spec APPROVED BY SIGNATURE Name / Title Note Please return 1 copy for your confirmation with your signature and ments. Approved By 2012-01-17 11:17:27 CST Checked By 2012-01-12 11:33:33 CST Prepared By 2012-01-11 10:57:04 CST Version 3.0 18 January 2012 The copyright belongs to CHIMEI InnoLux. Any unauthorized use is prohibited. 1 / 29 PRODUCT SPECIFICATION 1. GENERAL DESCRIPTION 1.1 OVERVIEW N140BGE-L22 is a 14.0” (14.0” diagonal) TFT Liquid Crystal Display module with LED Backlight unit and 40 pins LVDS...
