GBLC12
Features
- 350 Watts Peak Pulse Power per Line (tp=8/20µ s)
- Protects one I/O line
- Low clamping voltage
- Working voltages :
3.3V , 5V, 8V , 12V , 15V , 18V , 24V and 36V
- Low leakage current
- Suffix "G" indicates Halogen-free part, ex.GBLC03CG.
- Mechanical data
- Epoxy:UL94V-0 rated flame retardant
- Case : Molded plastic, SOD-323
- Terminals : Solder plated, solderable per
MIL-STD-750, Method 2026
- Polarity : Indicated by cathode band
- Weight : 0.0002 ounce, 0.005 gram
0.055 (1.40) 0.046 (1.18)
- Outline
SOD-323
0.071 (1.80) 0.059 (1.50)
Marking code
0.017 (0.43) 0.010 (0.25)
0.046 (1.17)Max.
0.006 (0.15) 0.003 (0.08)
0.107 (2.72) 0.097 (2.46)
Dimensions in inches and (millimeters)
- Applications
- Cell Phone Handsets and Accessories
- Microp ro cessor based equipment
- Personal Digital Assistants (PDA’s)
- Notebooks, Desktops, and Servers
- Portable Instrumentation
- Peripherals
- USB Interface
- Pin Configuration SOD -323
- IEC PATIBILITY
- IEC61000-4-2 (ESD) ±30k V...
