技 k Data Sheet e V1.1 特科 ce T 12K Embedded OTP ROM 矽Ch源ip Sour Hi‐Performance 16‐bit Multimedia Processor TEL: +86-0755-27595155 27595165 FAX: +86-0755-27594792 WEB:Http://.Chip Source Tek. E-mail: Sales@Chip Source Tek. Tony.Wang@Chip Source Tek. CST16P188B 16-bit Multimedia Processor 1. CST16P188B General Description The Tx P16TM is a high performance 16-bit MCU, pronounced as Tritan excellent-Processor16. It is the new generation putational kernel for CST16P161B series. It has initially aimed at the areas of controller and multimedia digital signal processing (DSP) application to demonstrate its profession. Tx P16 furnish with fast MAC architecture, which allows multiplication+accumulation instructions to be issued with access memory simultaneously during one cycles. The CST16P161B is equipped with Tx P16 and integrating input/output ports, PWM, Timer and Low Voltage Reset...etc on a chip. Furthermore, CST16P161B extend its external device connection capability such as Serial ROM/Flash. The 矽Ch源ip特So科ur技ce Tek internal memory capacity includes 12Kx16 program/data OTP ROM plus 3072x16 working SRAM. TEL: +86-0755-27595155 27595165 FAX: +86-0755-27594792 WEB:Http://.Chip Source Tek. E-mail: Sales@Chip Source Tek. Tony.Wang@Chip Source Tek. CST16P188B 16-bit Multimedia Processor 2. CST16P188B Features - High-performance RISC Tx P16 CPU ‧ 13Mhz@2.4Volt ~ 5.5Volt , 11Mhz@2.4Volt ~ 5.5Volt or 6.5Mhz@2.4Volt ~ 5.5Volt ‧ Built-in 3072x16 SRAM ‧ Hybrid Instruction and data memory share with 12Kx16 OTP ROM ‧ Embedded PC Stack Level 16 - Rich DSP function ‧ Hardware Circular Buffer support ‧ MAC putation power : 13MIPS (max.) ‧ Multi-Function Support: In MAC calculation, simultaneously access two operands from memory in one cycle ‧ Extend Dynamic Range: A 40-bit accumulator to ensure in 512 successive multiple+additions no overflows - Software-based audio processing technical 技 k ‧ADPCM , CELP , Melody synthesis up to 12channels ( Max ) -...
