SMF4L75CA Overview
Description
and Applications This new generation TVS is designed for transient overvoltage protection. The combination of small size and high ESD surge capability makes it ideal for use in: - Power management - Automotive applications - Battery contacts Mechanical Data - Package: DO-219AA - Package Material: Molded Plastic, "Green" Molding Compound.
Key Features
- 400W Peak Pulse Power Dissipation (10µs × 1000µs Waveform)
- 5V to 200V Standoff Voltages
- Provides ESD Protection per IEC61000-4-2 Standard: Air ±30kV, Contact ±30kV
- Excellent Clamping Capability
- Fast response time: typically less than 1.0ns for Uni-direction, less than 5.0ns for Bi-direction, from 0V to BV min
- Lead-Free Finish; RoHS Compliant (Notes 1 &
- Halogen and Antimony Free. “Green” Device (Note
- This part is qualified to JEDEC standards (as references in AEC-Q) for High Reliability
