Download SMF4L78A Datasheet PDF
SMF4L78A datasheet preview
SMF4L78A page 2
Page 2
SMF4L78A page 3
Page 3

SMF4L78A Key Features

  • 400W Peak Pulse Power Dissipation (10µs × 1000µs Waveform)
  • 5V to 200V Standoff Voltages
  • Provides ESD Protection per IEC61000-4-2 Standard
  • Excellent Clamping Capability
  • Fast response time: typically less than 1.0ns for Uni-direction
  • Lead-Free Finish; RoHS pliant (Notes 1 & 2)
  • Halogen and Antimony Free. “Green” Device (Note 3)
  • For automotive

Other SMF4L78A Datasheets

Manufacturer Part Number Description
Littelfuse Logo Littelfuse SMF4L78A TVS Diodes
ANOVA
ANOVA		 SMF4L78A Surface Mount Transient Voltage Suppressors
SEMIWILL Logo SEMIWILL SMF4L78A Surface Mount Transient Voltage Suppressors
Littelfuse Logo Littelfuse SMF4L78AT1G TVS Diodes
SEMIWILL Logo SEMIWILL SMF4L78CA Surface Mount Transient Voltage Suppressors

View all SMF4L78A datasheets →

SMF4L78A Description

and Applications This new generation TVS is designed for transient overvoltage protection. The bination of small size and high ESD surge capability makes it ideal for use in: Power management Automotive applications Battery contacts Package:.

SMF4L78A Applications

  • This part is qualified to JEDEC standards (as references in AEC-Q) for High Reliability. https://.diodes./quality/product-definitions/
