EC5604
FEATURES
- Wide Supply Voltage Range 6V to 20V
- Input range 500m V beyond the rails
- Rail-to-Rail Output Swing
- Large DC Voltage Gain 90d B (Typical)
- High slew rate 40V/μs
- Protection Function
- Over Temperature Protection (OTP)
- Over Current Protection (OCP)
- -3d B Bandwidth (unit gain) 30MHz
- ±350m A Output Short Circuit Current
- Unity-gain stable
- Ultra-small Package TSSOP-14
APPLICATIONS
- TFT-LCD Reference Driver
- Touch-Screen Display
- Wireless LANs
- Personal munication Devices
- Direct Access Arrangement
- Personal Digital Assistant (PDA)
- Active Filter
- Sampling ADC Amplifier
- ADC/DAC Buffer
- Electronic Notebook
- Office Automation
With features of 40V/μs high slew rate and 500ns of fast settling time, as well as 100m A (sink and source) of high output driving capability, the EC5604 is ideal for the requirements of flat panel Thin Film Transistor Liquid Crystal Displays (TFT-LCD) panel reference buffers application. Due to insensitive to power supply variation,...
