ELECTRICAL CHARACTERISTICS
PARAMETERS Frequency Mode of Oscillation Frequency Tolerance* Frequency Stability* Shunt Capacitance Load Capacitance Drive Level Operating Temperature* Storage Temperature Aging (First Year) CONDITIONS Fundamental @ +25°C (C option) -30 ~ +85°C (KY option) Co Specify in P/N DL Topr (Y option) Tstg @ +25°C ±3°C ECX-2236B MIN TYP MAX 12.000 60.000 ± 10 ± 10 3 8 100 -30 +85 -55 +125 ±1 UNITS MHz ppm ppm pF pF μW °C °C ppm Frequency (MHz) 12.000 ~ 15.999 16.000 ~ 19.999 20.000 ~ 29.999 30.000 ~ 39.999 40.000 ~ 60.000 ESR Ω Max. 130 70 50 40 30 Pad Connections 1 In/Out 2 Gnd 3 Out/In Figure 1) Top, Side, and Bottom 4 Gnd Crystal is symmetrical, pad 1 & 3 are interchangeable. Figure 2) Suggested land Chamfer on the bottom pad has no electrical significance. PART NUMBERING GUIDE: Example ECS-240-8-3p6aBtt-eCrnKY-TR ECS - FREQUENCY ABBREVIATION LOAD CAPACITANCE ECS 240 = 24.000 MHz See P/N Guide 8 = 8 pF 10=10 pF * Specify available options in P/N. † Contact ECS for availability over extended temp range.
