EMG1610
Overview
1.1. General Description
The EMG1610 includes a controller that integrates the 8051 core with peripheral circuits to perform Sine-Wave Field-oriented control (F.O.C.) of PMSM/BLDC motor applications. For rotor position detection, it support sensorless, Hall latch, Hall element, and BEMF input. In addition, system level peripheral functions, such as ADC, UART interface, IR decoder, watchdog timer, current sensing, short circuit protection (SCP) and locked-rotor protection are integrated to reduce ponent count, PCB size and system cost.
The device also includes three half-bridge configuration with an external bootstrap network up to 600V for 3-phase motor driving applications.
1.2. Features
Motor Controller
- Operation Frequency 24MHz
- High-performance 8051 Microcontroller
- Vector Interrupt Controller, 13 Interrupt Sources
- Operating Voltage Range: 4.5V to 5.5V
- Memory size :
- 18KB Flash Program Memory
- 256 x 8bit IRAM
- 2K x 8bit XRAM
- Up to 18 General-Purpose Input /...
